[iScope fluorescence] Life Science Upright Microscopes 정립 현미경

Quantity:

설명

Life Science Upright Microscopes

정립 현미경

iScope fluorescence

is-3152_pli-3

For biological and medical applications fluorescence microscopes are used to observe certain parts of living cells and tissues with help of fluorophores. One or more fluophores are added to the parts of the specimen to be observed. When the fluorophores are exposed to so-called exicitation light, the excitation energy is absorbed by the fluorophore that start emitting so-called emission light that can be observed by the microscope. One can distinguish tumor cells from other cells, follow biological processes or prove the presence or absence of antibodies, etc

The excellent optics and mechanical components make the iScope a state-of-the art microscope that is suitable for fluorescence applications in Life Science and Biotechnical fields

The iScope fluorescence microscopy can be supplied with:

• 6-position rotating attachment with 100 W mercury vapor light source
• 3-position slider attachment with 100 W mercury vapor light source
• 1-position slider attachment with a 3 W NeoLED 465-475 nm blue light source
• 1-position slider attachment with a 3 W NeoLED 520-530 nm green light source



iscope_fluor_icons

Highlights

  • HWF 10x/22 mm eyepieces
  • Binocular and trinocular models
  • Optional ergonomic tilting head
  • Quintuple revolving nosepiece
  • E-plan, plan and plan fluarex corrected ioS objectives
  • 216 mm x 150 mm rackless stage with integrated X-Y stage
  • Optional ceramic stage
  • Height adjustable abbe condenser n.a. 1.25
  • Coarse and fine adjustment
  • Diascopic intensity adjustable 3 W NeoLED Köhler illumination
  • Epi-fluorescence 100 W HBo mercury vapor
  • Epi-fluorescence 460-495 nm or 510-550 nm 3 W leD
  • iCare sensor for energy saving
  • CSS – Cable Storage System

Models

6-positions rotating attachment

• With 100 W mercury vapor light source

The 6-positions rotating fluorescence attachments are supplied with a standard 100 W HBO mercury vapor light source for broad powerful light spectrum. Supplied with standard fluorescence filters sets for excitation in the blue and green light spectrum and a UV protection shield

2016-11-13-150327

3-positions slider attachment

• With 100 W mercury vapor light source

The 3-positions slider fluorescence attachments are supplied with standard 100 W HBO mercury vapor light source for broad powerful light spectrum. Supplied with standard fluorescence filters sets for blue and green excitation and a UV protection shield

2016-11-13-150344

1-position slider attachment

• With a 3 W NeoLED 465-475 nm blue light source (/LB)
• With a 3 W NeoLED 520-530 nm green light source (/LG)

Single position slider fluorescence attachments are supplied with either with a 460-495 nm 3 W LED for blue excitation or a 510-550 nm 3 W LED light source for green excitation. Supplied with standard fluorescence filters sets for blue (/LB) or green excitation (/LG)

2016-11-13-150357

Specifications

EYEPIECE(S)
Extended EWF 10x/22 mm eyepieces, Ø 30 mm tubes. Eyepieces can be secured to the tubes

HEADS
Binocular and trinocular Siedentopf type heads are with 30° inclined tubes, interpupillary distance from 48 to 76 mm and is equipped with diopter adjustment(s). An unique rotating system allows the ergonomical positioning of both tubes in a high (431 mm) and in a low position (397 mm). The trinocular head comes with a Ø 23.2 mm photo port. An optional ergonomic titling head and corresponding Ø 23.2 mm photo tube attachment are also available (only infinity corrected models).

To order an iScope with tilting head use reference IS.3158-xxx

NOSEPIECE
Revolving and reversed nosepiece for maximum 5 objectives

OBJECTIVES

iscope_fluor_objectives

STAGES
• 216 x 150 mm rackless stage equipped with double slide holder and integrated 79 x 52 mm mechanical stage. The iScope® rackless stage has no protruding parts, enabling more smooth movements and is safer

• 220 x 157 mm ceramic stage with integrated 75 x 50 mm mechanical stage protects with a very tough ceramic surface, against marks and scratches. The surface also ensures stray light not to be reflected from the stage into the objective

CONDENSER FOR BRIGHTFIELD
The standard height adjustable Abbe N.A. 1.25 condenser for brightfield accepts sliders with phase annuli suitable for plan phase 10x/20x or S40x/S100x oil immersion IOS objectives for economical phase contrast. With magnification indication. A slider with a simple dark stop for dark field up to 400x magnification is also available

CONDENSER FOR ZERNIKE PHASE CONTRAST
An optional height adjustable Zernike NA. 1.25 phase contrast disc condenser with plan phase 10/20/S40x and S100x oil immersion objectives and dark field stop position for dark field contrast up to 400x magnification

FOCUSING
Coaxial coarse and fine adjustments, 200 graduations, 1 μm per graduation, 200 μm per rotation, total travel approximately 24 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustments are equipped with friction control

ILLUMINATION
3 W adjustable Köhler NeoLED diascopic illumination with internal 100-240 V power supply

The innovative NeoLED design offer larger apertures, allowing the optical system of the iScope microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics. Other benefits of the NeoLED is the low energy consumption, no heating and a long operating lifetime

The Köhler illumination on models with IOS plan and plan phase infinity corrected system provides high contrast and a maximum achievable resolving power of the optics. Also available for other models as an option

iscope_fluor_6_blocks

ILLUMINATION FOR FLUORESCENCE
The 6-positions rotating or 3-positions slider fluorescence attachments are supplied with standard 100 W HBO mercury vapor light source for broad powerful light spectrum and 100-240 V external power supply with indication of the life time of 100 W HBO lamp.

Supplied with standard fluorescence filters sets for blue and green excitation and a UV protection shield

The iScope fluorescence microscopes equipped with a 100 W mercury vapor light source can be supplied with more specific, optimized and application related fluorescence filters sets

Two single position fluorescence attachments are supplied with 460-495 nm 3 W LED for blue excitation or 510-550 nm 3 W LED light source for green excitation and 100-240 Vac/7.5 Vdc external power supply. Supplied with standard fluorescence filters sets for blue and green excitation

STANDARD GENERAL PURPOSE FLUORESCENCE FILTER SETS

iscope_fluor_graphic

ICARE SENSOR
The unique iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the microscope automatically switches off shortly after microscopists step away from their position

CSS – CABLE STORAGE SYSTEM
iScope allows users to easily insert the power cable into the backside of the instrument, which enables easy storage. The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope

CONFIGURATIONS
The iScope microscope is available in many configurations and can be upgraded with a variety of contrast types.

• Do you want to see the standard models?
• Do you want to see the phase contrast models?
• Do you want to see the polarisation models?
• Do you want to see the darkfield models?
• Do you want to see the fluorescence models?

PACKAGING
Supplied with power cord, dust cover, a spare fuse, user manual and 5 ml immersion oil for models with S100x objective. Models with 100 W mercury vapor light source have a UV protection shield. All packed in polystyrene boxes

Accessories

IS.6215
WF15x/16 mm eyepiece, Ø 30 mm tube
IS.6220
WF20x/12 mm eyepiece, Ø 30 mm tube
IS.6299
Pair of eyecups, Ø 30 mm tube
IS.7104
E-plan EPL 4x/0.10 objective
IS.7110
E-plan EPL 10x/0.25 objective
IS.7120
E-plan EPL 20x/0.40 objective
IS.7140
E-plan EPL S40x/0.65 objective
IS.7160
E-plan EPL S60x/0.85 objective
IS.7100
E-plan EPL S100x/1,25 objective
IS.7710
Plan PLPH 10x/0.25 phase contrast objective
IS.7720
Plan PLPH 20x/0.40 phase contrast objective
IS.7740
Plan PLPH S40x/0.65 phase contrast objective
IS.7700
Plan PLPH S100x/1.25 phase contrast objective
IS.8804
E-plan EPLi 4x/0.10 IOS infinity corrected objective
IS.8810
E-plan EPLi 10x/0.25 IOS infinity corrected objective
IS.8820
E-plan EPLi 20x/0.,40 IOS infinity corrected objective
IS.8840
E-plan EPLi S40x/0.65 IOS infinity corrected objective
IS.8800
E-plan EPLi S100x/1.25 IOS infinity corrected objective
IS.7204
Plan PLi 4x/0.10 IOS infinity corrected objective
IS.7210
Plan PLi 10x/0.25 IOS infinity corrected objective
IS.7220
Plan PLi 20x/0.40 IOS infinity corrected objective
IS.7240
Plan PLi S40x/0.65 IOS infinity corrected objective
IS.7260
Plan PLi S60x/0.85 IOS infinity corrected objective
IS.7200
Plan PLi S100x/1.25 IOS infinity corrected objective
IS.8910
Plan PLPHi 10x/0.25 phase contrast IOS infinity corrected objective for iScope
IS.8920
Plan PLPHi 20x/0.40 phase contrast IOS infinity corrected objective for iScope
IS.8940
Plan PLPHi S40x/0.65 phase contrast IOS infinity corrected objective for iScope
IS.8900
Plan PLPHi S100x/1.25 phase contrast IOS infinity corrected objective for iScope
IS.7404
Plan Fluarex PLFi 4x/0.10 IOS infinity corrected objective
IS.7410
Plan Fluarex PLFi 10x/0.25 IOS infinity corrected objective
IS.7420
Plan Fluarex PLFi 20x/0.40 IOS infinity corrected objective
IS.7440
Plan Fluarex PLFi S40x/0.65 IOS infinity corrected objective
IS.7400
Plan Fluarex PLFi S100x/1.25 IOS infinity corrected objective
IS.9149
Telescope for alignment of for phase contrast annuli, Ø 23,2mm tube
IS.9102
Standard Abbe condenser 1,25 NA with slot for darkfield and phase contrast sliders
IS.9105
Swing-out 0,9/1,25 condenser
IS.9162
Phase contrast slider set with 10x and S40x PLPHi IOS infinity corrected objectives and annuli for 10x/S40x
IS.9600
Polarisation filter 45 mm for lamp house
IS.9749-6
Empty filer block for 6 positions fluorescence attachment of iScope
IS.9749-3
Empty filer block for 3 positions fluorescence attachment of iScope
IS.9749-1
Empty filer block for 1 positions fluorescence attachment of iScope
IS.9753
Empty rail for 3 positions fluorescence attachment of iScope
SL.5500
NeoLED™replacement unit for iScope
IS.9993
NeoLED™replacement unit for iScope
AE.5130
Universal Ø 23.2 mm tube adapter with built-in 2x lens for SLR photo camera with APS-C sensor. Needs T2 adapter
AE.5025
T2 ring for Nikon D SLR digital camera
AE.5040
T2 ring for Canon EOS SLR digital camera
PB.5155
Microscope slides 76 x 26 mm, ground edges, 50 pieces
PB.5165
Cover glasses 18 x 18 mm, 0,13-0,17 mm, 100 pieces
PB.5168
Cover glasses 22 x 22 mm, 0,13-0,17 mm, 100 pieces
PB.5255
Immersion oil, 25 ml. Refraction index n = 1,482
PB.5274
Iso propyl alcohol 99%, 200 ml
PB.5275
Cleaning kit: lens fluid, lint free lens tissue/paper, brush, air blower, cotton swabs
